Cyclone 10 GX

ARD_A_CYCX

Cyclone 10 GX

The ARD_A_CYCX is a scalable power supply designed to provide power to Intel Altera Cyclone V devices. The design is scalable and flexible to support the FPGA family SKUs from the most basic 10CX085 to the most feature-rich and power hungry 10CL120. The programmable system integration, upward scalability, high performance/watt numbers and reduced time-to-market features of the AnDAPT’s AmP PMIC makes it an ideal match for handling power management responsibilities of Cyclone 10 GX FPGA solutions.


POWER TREE MAPPING – CYCLONE 10 GX

#RailSeqPower ComponentTypeUpstream RailVinput (V)Vout (V)Iout (A)AnDAPT PMIC
1VCCINT1C200Sync BuckPVIN120.96ARD_A_CYCX_IC1
2VCCINT_TRX2C200Sync BuckPVIN120.950.6ARD_A_CYCX_IC1
3HPS1V83C200Sync BuckPVIN121.83ARD_A_CYCX_IC1
4VCCIO5C200Sync BuckPVIN121.51ARD_A_CYCX_IC1

ANDAPT SOLUTION

ARD_A_CYCX AnDAPT Solution

THERMAL VIEW IC1

ARD_A_CYCX Thermal View IC1

DESIGN VIEW IC1

ARD_A_CYCX Design View IC1
